Water Pressure Reducing Valve


200P Pressure Reducing Valve is a directly acting adjusting pressure reducing valve, which uses the membrane hydraulic operation and can be mounted vertically or horizontally in the water supply, fire-fighting or other pure water system. The outlet pressure can be controlled at a relatively stable value within a certain range.
It is inner-thread connected, features by the exquisite shape, easy installation etc. and is equipped with a built-in filter screen to make it mounted and operated integrally, without being blocked up with foreign matters, And it is safer and more reliable.

water pressure reducing valve
water pressure reducing valve

Technical parameters

Model PN(MPa) Body test pressure Seat ring test pressure Max. flow rate (M/S) Pressure reduction range
200P-10T 1.0 1.5 1.1 6 = 0.7MPa
200P-16T 1.6 2.4 1.76


Part Body, disc Filter screen, nut, washer,
spring gland
Spring O-ring
Material Al-bronze Stainless steel 60Si2Mn Chemigum


DN(mm) Dimensions
L H H1
15 112 170 130
20 112 183 130
25 135 189 143
32 165 242 195
40 192 273 222
50 231 307 252
